12 Volt DC Lamp Dimmers

Dims up to 60 watts (4.2 Amps) of incandescent, halogen, or LED lighting reducing heat and power drain on batteries.

For new custom installations or to replace an existing on/off switch in an RV lamp fixture to create low-light ambiance.

Perfect for RVs, trailers, boats, cars, trucks, or anywhere 12 volt DC power is present. Fits in small spaces where other dimmers can't.

Included with the dimmer switch are all the parts you need to install; mounting nut, knob, and wire twist nuts. (Pictured lamp fixture is not included.)

Features and Specifications:

  • Replaces existing push-button switch
  • For incandescent, halogen and LED lamps
  • Saves energy
  • Cool and efficient operation
  • Low profile
  • No special wiring needed
  • Easy to install!
  • Maximum wattage: 60 watts
  • 1 year limited warranty
  • Engineered and manufactured in the USA

General Specifications:

  • Input voltage: 6-15 volts DC
  • Temp. range: 0°-70°C
  • Size: 0.525" L x 0.535" W x 0.450" H
  • Min. Depth req'd: 0.510"
  • Pulse Width Modulated Semiconductor Switch

Wholesale Inquiries

PCA Electronics Inc. manufactures a broad selection of electromagnetic components for computer, telecommunications, and medical OEMs.

If you are interested in using our EPL1012 Series dimmers in your application, please contact us for OEM pricing.


ISO9001:2015 certifications in all of our global sales and manufacturing facilities.
